Shuttle XS XS350VA – Connectors
Front Panel Back Panel
1 4-in-1 card reader A Microphone input
2 USB connector B Head phone output (line out)
3 Power button with C Network connector (RJ45)
power and hard disk LED D 4x USB connectors
4 Stand E Hole for the Kensington lock
F VGA connector
G Connector for power adapter
H Stand
*) Note: The optical drive is not included.
Warning:
Please make sure the system is always
placed upright using either its stand or
the optional VESA mount. Ventilation
holes must not be blocked to ensure
sufficient cooling.
